The one about rendering and displaying code examples in ERB

I have been building a component showcase page for an internal design system, using Sinatra and ERB templates. The page renders each UI component visually and, right below it, offers a toggle to reveal the source code that produced it.

The problem: code duplication

The naive approach looks like this:

<div class="example">
  <%= primary_button "Button" %>
</div>

<%= erb :_toggle_code, locals: { code: 'primary_button "Button"' } %>

The first block calls the Ruby helper to render the actual button. The second block passes the same call as a string to a partial that displays it:

<code><%= code %></code>

This works, but the code is duplicated. Update one, forget the other, and they drift apart. With dozens of examples, that drift becomes inevitable.

Single source of truth

The idea is straightforward: store the code as a string, then eval it to render the component, and display the source.

I wrapped the logic in a helper module:

def render_code_example(code)
  eval(code.strip, binding)
end

Disclaimer: this is an internal tool, never use this pattern with untrusted or user-generated input.

That worked for simple, single-line examples:

<div class="example">
  <% example = 'primary_button "Button"' %>

  <%= render_code_example(example) %>

  <%= erb :_toggle_code, locals: { code: example } %>
</div>

However, I found that examples with multiple lines, like a fieldset containing several radio buttons, would only render the last one. eval returns the value of the last expression, so intermediate lines were lost:

<div class="example">
  <%
    example = <<-CODE
      radio_input(name: "contact", value: "email", id: "contact_email", label: "Email")
      radio_input(name: "contact", value: "phone", id: "contact_phone", label: "Phone")
    CODE
  %>

  <fieldset>
    <legend>Select your preferred contact method:</legend>
    <%= render_code_example(example) %>
  </fieldset>

  <%= erb :_toggle_code, locals: { code: example } %>
</div>

The fix was to split the string into lines and eval each one independently:

def render_code_example(code)
  code.strip.split("\n").map { |line| eval(line.strip, binding) }.join("\n")
end

The method splits the string into lines, evaluates each one in the current binding (which has access to all the component helper methods), and joins the results. Each line is an independent Ruby expression that returns HTML.

The example is now defined once: render_code_example executes it, and the _toggle_code partial displays it.

That solved the rendering side, but the output code was not quite right. The <code> element collapses whitespace by default, so both radio buttons are shown in a single line:

radio_input(name: "contact", value: "email", id: "contact_email", label: "Email") radio_input(name: "contact", value: "phone", id: "contact_phone", label: "Phone")

Wrapping the output in a <pre> tag preserves the line breaks:

<pre><code><%= code %></code></pre>

That fixed the formatting, but introduced a new issue. The heredoc (<<-CODE) preserves the indentation from the ERB template, so the output code was rendered with leading spaces:

            radio_input(name: "contact", value: "email", id: "contact_email", label: "Email")
            radio_input(name: "contact", value: "phone", id: "contact_phone", label: "Phone")

Switching to a squiggly heredoc (<<~CODE) stripped the common leading indentation automatically.

Finally, since the code string may contain HTML characters, the partial escapes it before rendering:

<pre><code><%= escape_code_example(code) %></code></pre>

That new helper uses Rack::Utils.escape_html to handle the escaping.

This eliminated the duplication problem for all examples where each line is an independent Ruby expression.

The new challenge: HTML components

Then a new table component was needed, and instead of building a Ruby helper the first approach was a CSS-only component: plain HTML with custom styles.

<table class="fw-table">
  <thead>
    <tr>
      <th>Name</th>
      <th>Email</th>
    </tr>
  </thead>
  <tbody>
    <tr>
      <td>Alice</td>
      <td>[email protected]</td>
    </tr>
  </tbody>
</table>

You cannot eval HTML. It is not Ruby. A different approach was needed.

When ERB processes a template, it appends the rendered content to a string buffer. In Sinatra, that buffer is the instance variable @_out_buf. The idea was to record the buffer's length before a block executes, let the block run, and then slice out everything that was appended during it:

def capture_html(&block)
  buffer = @_out_buf
  pos = buffer.length
  yield
  dedent(buffer.slice!(pos..-1))
end

The slice! call is important: it removes the captured content from the buffer so it is not rendered twice.

There was one more problem. The captured HTML carries the indentation of the ERB template it lives in. Since the code display uses a <pre> tag, that indentation shows up as unwanted leading spaces.

A dedent helper strips the common leading whitespace, normalizing the output regardless of how deeply nested the ERB block was:

def dedent(text)
  margin = text.scan(/^[ \t]*(?=\S)/).map(&:size).min || 0

  text.gsub(/^[ \t]{#{margin}}/, '').strip
end

With those two helpers in place, the ERB usage followed the same single-definition pattern:

<% example = capture_html do %>
  <table class="fw-table">
    <thead>
      <tr>
        <th>Name</th>
        <th>Email</th>
      </tr>
    </thead>
    <tbody>
      <tr>
        <td>Alice</td>
        <td>[email protected]</td>
      </tr>
    </tbody>
  </table>
<% end %>

<%= example %>

<%= erb :_toggle_code, locals: { code: example } %>

Write the HTML once. capture_html grabs it as a string. Output it for rendering, pass it for display.

Unification: block detection

The CSS-only table did not last long. It was eventually replaced with a Ruby block DSL, where the table is built through nested method calls:

table do
  table_head do
    table_row do
      table_header_cell("Name")
      table_header_cell("Email")
    end
  end
  table_body do
    table_row do
      table_cell("Alice")
      table_cell("[email protected]")
    end
  end
end

Now render_code_example had to handle this too. But unlike the radio buttons from before, these lines are not independent expressions. They form a single do...end block, and evaluating table do in isolation is a syntax error.

The fix was to detect whether the code is a block expression and, if so, evaluate it as a whole instead of line by line:

def render_code_example(code)
  stripped = code.strip

  if block_expression?(stripped)
    eval(stripped, binding)
  else
    stripped.split("\n").map { |line| eval(line.strip, binding) }.join("\n")
  end
end

private

def block_expression?(code)
  code.match?(/\bend\z/)
end

The check is simple: if the code ends with the end keyword, treat it as a block. \b ensures it matches the whole word, and \z anchors to the end of the string.

In the ERB template, multi-line code uses a heredoc to keep things readable:

<%
  example = <<~CODE
    table do
      table_head do
        table_row do
          table_header_cell("Name")
          table_header_cell("Email")
        end
      end
      table_body do
        table_row do
          table_cell("Alice")
          table_cell("[email protected]")
        end
      end
    end
  CODE
%>

<%= render_code_example(example) %>

<%= erb :_toggle_code, locals: { code: example } %>

With this change, capture_html and dedent were no longer needed. Every component in the showcase now uses Ruby helpers, so the buffer-interception approach was removed entirely.

Conclusion

The core idea never changed: define each example once, then use it for both rendering and display. What evolved was the mechanism: from eval on single lines, to line-by-line splitting, to buffer interception for raw HTML, and finally to block detection when the Ruby DSL arrived. Each iteration solved a real problem introduced by the previous one.

The final code is straightforward, but it earned that simplicity one edge case at a time:

module Helpers
  module CodeExample
    def escape_code_example(*strings)
      Rack::Utils.escape_html(strings.join("\n\n"))
    end

    def render_code_example(code)
      stripped = code.strip

      if block_expression?(stripped)
        eval(stripped, binding)
      else
        stripped.split("\n").map { |line| eval(line.strip, binding) }.join("\n")
      end
    end

    private

    def block_expression?(code)
      code.match?(/\bend\z/)
    end
  end
end

If you have an interesting alternative approach to this problem, feel free to share it with me.

Thank you for reading and see you in the next one!
